(4) Parameter and construction
Source parameter Transfer size and status Destination parameter
A Bank/CH Type B Transfer size C Bank/CH Type
A+1 Leading address C+1 Leading address
Transfer parameter table
Transfer object Type Leading address Bank/CH Transfer size Status flag
T2N 0 to 127 1 to 128
XW/YW register
T3H
00H
0 to 511
0
1 to 256
None
W register 01H 0 to 2047 0 1 to 256 None
LW register 02H 0 to 255 0 1 to 256 None
T2N 0 to 255
RW register
T3H
03H
0 to 999
0 1 to 256 None
D register 04H 0 to 8191 0 1 to 256 None
T2N 0 to 1023
F register
T3H
03H
0 to 32767
0 1 to 256 None
05H 0 to 8191 1 to 15 1 to 256 None
0 to 65535 1
Expanded F register
(IC memory card)
T
3
H
06H
0 to 57343 2
1 to 256 None
Expanded F register
(T2N internal memory)
T
2
N 05H 0 to 8191 1 to 3 1 to 256 None
T2N 1 TOSLINE-S20LP
scan memory
T3H
10H 0 to 4095
1 or 2
1 to 256 None
T2N 0 to 2047 EEPROM
T3H
20H
0 to 8191
0
1 to 256
(Note 1)
None
(Note 1) When the communication is transfer source (receiving), the transfer size is 1 to 256.
When it is destination (transmitting), the transfer size is 1 to 128 for T3H, 1 to 32 for
T2N.
