Problem Solving 69
4 Pull out any paper you see jammed inside the machine.
1 ABC 2 DEF 3
GHI 4 JKL 5 MN 6
PRS 7 TUV 8 WXY 9
* OQZ 0 #
AUTO REC SEARCH
SELECT FUNCTION AUTO DIAL
HYPHEN REDIAL
COPY HOOK V. REQUEST
PHOTO EX FINE FINE STD LIGHT NORMAL DARK ALARM STOP STAR T
5 Pull out the paper tray. If any paper in the tray is
damaged, remove and replace it.
6 Push the paper down until it is under the plastic tabs.
7 Make sure the paper stop in the tray is properly
adjusted: not too loose, not too tight.
8 Slide the paper tray all the way back into the OKIFAX.
9 Place the image drum unit back into your OKIFAX. To
make sure that the image drum is positioned corrctly,
press down firmly on both of the locations on the drum
marked “PUSH.”
1 ABC 2 DEF 3
GHI 4 JKL 5 MN 6
PRS 7 TUV 8 WXY 9
* OQZ 0 #
C PHOTO EX FINE FINE LIGHT NO RMAL
PUSH
PUSH
