2-2 RS-232C/RS-422 Serial Interface Option
Control Panel MENU structure
About this Chapter
This chapter lists the Serial Interface setup features and available selections via the control panel menus.
The Serial Interface connector pinouts are listed. Troubleshooting error messages appearing on the
printer’s control panel are also discussed.
Control Panel MENU structure
When the RS-232C/RS-422 serial interface is installed, the printer control panel menu structure is
enhanced as shown in the following table. The shaded areas denote additional features and settings rele-
vant to the RS-232C/RS-422 interface.
Menu
Paper Menu
Interface Menu
Port
Parallel
Serial
Parallel Setup On
Serial Setup Off
Interpreter
Auto Switch
PCL
Postscript 3
Format
Normal
Binary
Raw
Serial Mode
RS232
RS422
Baud Rate
1200
2400
4800
9600
19200
38400
57600
115200
Data Bits
7
8
Stop Bits
1
2
Parity
