Model 990 Specifications
Preamplifier Analog Section
Input Impedance @ 1V
Phono (MM) 2.5mV / 47k Ω
Line (CD, Tape, Video) 200mV / 47k Ω
IMD @ 60Hz to 7kHz .09% (4:1 SMTPE, 8 Ω, output 1V)
Output Level (1k Ω load)
Tape Mon Rec 200mV
Pre Out 1V
THD @ 1V .05% (1kHz)
Maximum Output 9V
Volume Range (Main) -76dB to +8.0dB (1dB resolution)
Bass Management
High-Pass Slope Crossover Frequency
(Small Speaker Setting) (Adjustable 40/60/80/100/120/150/200Hz)
12 dB/octave (2nd order)
Low-Pass Slope (Subwoofer) 24 dB/octave (4th order), 40-200Hz as above
Tone Control
Bass Center Frequency/Range 100Hz ± 6dB
Treble Center Frequency/Range 10KHz ± 6db
Frequency Response
Phono (MM) 30Hz to 20kHz ± 1dB
Line 10Hz to 100kHz ± 1dB
S/N Ratio (ref. 2.3Vrms) >102dB
IMD (CCIF at 15kHz & 1 kHz) 0.01%
S/N Ratio (ref. 2.0Vrms A-weighted) 97dB
FM Tuner Section
Usable Sensitivity (THD 3%, S/N 30dB) 17.2dBf
50db Quieting Sensitivity
Mono 25.2dB
Stereo 43.2dB
S/N Ratio (60dBf)
Mono 72dB
Stereo 68dB
THD (65dBf)
Mono 0.2%
Stereo 0.3%
Stereo Separation 40dB typ.
Capture Ratio 3.0dB
IF Rejection Ratio 120dB
Frequency Response 20 Hz to 15 kHz ± 1.5dB
AM Tuner Section
Usable Sensitivity 12.5mV
S/N 51dB
Selectivity 30dB
Video Section (NTSC Format)
Bandwidth
Composite & S-Video 6 MHz –3dB
Component >100MHz
Input Sensitivity @ 75 Ω
Composite & S-Video 1.0Vp-p
Component R-Y Signal 0.5Vp-p
Component B-Y Signal 0.5Vp-p
Component Y Signal 1.0Vp-p
Digital Audio
All digital audio inputs and outputs are to S/PDIF electrical (75 Ω, 0.5Vp-p),
S/PDIF optical (Toslink), or AES / EBU (110 Ω, 5Vp-p) standards as appropriate.
Processor Crystal CS49400
Audio Converters
Digital to Analog Analog Device AD1852 24-bit/192kHz
Analog to Digital AKM AK5380
Stereo Asynchronous Sample
Rate Converter Analog Device AD1896
General
Supply Voltage 120V, 60Hz only
Power Consumption 50W
Dimensions
Width 17.38 inches / 441.5 mm
Height 7.75 inches / 196.9 mm
Depth 17.75 inches / 450.9 mm
Weight 28 lbs. / 12.7 kg
Trigger Outputs 1, 2 (User Assignable) Sequential Delay 50 mA @ 12 VDC
Specifications
