39
Setup —Continued
Sp Config (Speaker Configuration)
With the Speaker Configuration, you can
specify how may speakers you’re using.
Note:
• Before you change this setting, turn down
the volume.
■ Subwoofer
Yes:
Select if a subwoofer is used (default).
No:
Select if no subwoofer is used.
■ Front
Small:
Select if the front speakers are small
(default).
Large:
Select if the front speakers are large.
Note:
• If the Subwoofer setting is set to No, this
setting is fixed at Large and does not
appear.
■ Center
Small:
Select if the center speaker is small.
Large:
Select if the center speaker is large.
None:
Select if no center speaker is connected
(default).
Note:
• If the Front setting is set to Small, the
Large option cannot be selected.
■ Surround
Small:
Select if the surround speakers are small.
Large:
Select if the surround speakers are large.
None:
Select if no surround speakers are con-
nected (default).
Note:
• If the Front setting is set to Small, the
Large option cannot be selected.
■ Crossover
This setting only applies to the speakers that
you specified as Small.
To get the best bass performance from your
speaker system, you need to set the crossover
frequency according to the size and frequency
response of your speakers.
Use the diameter of the smallest speaker in
your system when choosing the crossover fre-
quency.
* Choose the setting suitable for the speaker.
Notes:
• For a more accurate setting, look up the
frequency response in the manuals supplied
with your speakers and set accordingly.
• Choose a higher crossover frequency if you
want more sound from your subwoofer.
■ Double Bass
With the Double Bass function, you can boost
bass output by feeding bass sounds from the
front left, right, and center channels to the
subwoofer.
On:
Double Bass function on. Bass from the
front left and right channels is also fed to
the subwoofer (default).
Off:
Double Bass function off.
Note:
• If the Subwoofer setting is set to No, or the
Front setting is set to Small, this setting
does not appear.
Speaker cone diameter
Crossover
frequency
Over 8 in. (20 cm) 40/50/60Hz*
6-1/2 to 8 in. (16–20 cm) 80Hz
5-1/4 to 6-1/2 in. (13–16 cm) 100Hz
3-1/2 to 5-1/4 in. (9–13 cm) 120Hz
Under 3-1/2 in. (9 cm)
150Hz (default)/
200Hz*
