Oki C 5200n - Manual (Page 75)

CLEARING PAPER JAMS > 75
9. Lower the top cover down but do not press down to latch it
closed yet. This will protect the drums from excessive
exposure to room lighting while you check the remaining areas
for jammed sheets.
10. Open the rear exit tray (5) and check for a sheet of paper in the
rear path area (6).
> Pull out any sheets found in this area.
> If the sheet is low down in this area and difficult to
remove, it is probably still gripped by the fuser. In this
case raise the top cover, reach around and press down
on the fuser pressure release lever (4).
11. If not using the rear exit tray, close it once paper has been
removed from this area.
5
6
4
