Caution – Oki C8800 User Manual
Page 166

Clearing paper jams > 166
forwards into the internal drum cavity and withdraw the
sheet.
>
To remove a sheet from the central area of the belt (2),
carefully separate the sheet from the belt surface and
withdraw the sheet.
>
To remove a sheet just entering the fuser (3), separate
the trailing edge of the sheet from the belt, push the fuser
pressure release lever (4) towards the front and down to
release the fuser’s grip on the sheet, and withdraw the
sheet through the drum cavity area. Then allow the
pressure release lever to rise again.
CAUTION!
Do not use any sharp or abrasive objects to separate
sheets from the belt. This may damage the belt
surface.
4
2
3
1
NOTE:
If the sheet is well advanced into the fuser (only a short
length is still visible), do not attempt to pull it back. Follow the
next step to remove it from the rear of the printer.
