The following accessories may be available
depending on the area which it was purchased.
Conversion plug × 1
(Use this plug if the power cord plug of the
TX-SR800 does not fit your AC outlet. Shape
may vary depending on the area which it was
purchased.)
75/300 Ω antenna adapter × 1
Features
Supplied accessories
Check that the following accessories are supplied with the TX-SR800.
AM loop antenna × 1 FM indoor antenna × 1
Amplifier Features
■ 100 Watts per channel min. RMS. into 8 Ω 2
channel driven, from 20 Hz to 20 kHz with no more
than 0.08 % total harmonic distorrtion (FTC )
■ 2 × 160 Watts into 6 Ω, 1,000 Hz (EIAJ )
■ 7 Channel Amplifier
■ Wide Range Amplifier Technology (WRAT)
■ Linear Optimum Gain Volume Circuitry
■ 192 kHz/24 Bit D/A Converters (except for
Surround Back L/R)
■ Zone-2 Capability
Audio/Video Features
■ THX
® Surround EX ®
■ THX Select Certified
■ Dolby
®* Digital, Dolby Digital EX, Dolby Pro
Logic II
■ DTS, DTS-ES Discrete 6.1, DTS-ES Matrix 6.1,
DTS Neo:6, and DTS 96/24
■ Theater-Dimensional TM Virtual Surround Mode
■ Non-Scaling Configuration
■ Onscreen displays (Basic Menu/Advanced Menu)
■ 2 Wideband Component-Video Inputs/1 Output
■ Composite to S-Video Conversion
■ 6 S-Video Inputs/3 Outputs
■ 6 Assignable Digital Inputs (3 optical/3 Coaxial),
1 outputs, and 1 Digital Input (optical)
■ Pre Out Terminals for Front L/R, Center,
Surround L/R, Surround back L/R or Zone 2 L/R
and Subwoofer
FM/AM Tuner Features
■ 40 FM/AM random presets
■ FM auto tuning
Other Performance Features
■ VLSC (Vector Linear Shaping Circuitry) for L/C/
R channels (Other than US & Canadian models
and Australian models)
■ IntelliVolume
■ Character Input
■ Powerful backlit/preprogrammed learning
remote with macro and mode-key LEDs
* Manufactured under license from Dolby Laboratories.
“Dolby,” “Pro Logic,” “Surround EX” and the double-D symbol are
trademarks of Dolby Laboratories.
• “Theater-Dimensional” is a trademark of Onkyo Corporation.
• Lucasfilm THX and THX are trademarks or registered trademarks of
THX Ltd. All rights reserved. Used under authorization.
• Re-Equalization and the “Re-EQ” logo are trademarks of THX Ltd.
Manufactured under license of THX Ltd.
• Manufactured under license from Digital Theater Systems, Inc. US Pat.
No. 5,451,942, 5,956,674, 5,974,380, 5,978,762 and other world-wide
patents issued and pending. “DTS,” “DTS-ES Extended Surround” and
“Neo:6” are trademarks of Digital Theater Systems, Inc. © 1996, 2000
Digital Theater Systems, Inc. All Rights Reserved.
• Xantech is a registered trademark of Xantech Corporation.
• Niles is a registered trademark of Niles Audio Corporation.
THX Select
Before any home theatre component can be THX Select
certified, it must pass a rigorous series of quality and
performance tests. Only then can a product feature the THX
Select logo, which is your guarantee that the Home Theatre
products you purchase will give you superb performance for
many years to come. THX Select requirements define
hundreds of parameters, including power amplifier
performance, and pre-amplifier performance and operation
for both digital and analog domains. THX Select receivers
also feature proprietary THX technologies (e.g., THX Mode,
see page 52) which accurately translate film soundtracks for
home theater playback.
Remote controller × 1
Batteries (AA, R6 or UM-3) × 2
Speaker cable label × 1
(See page 21.)
Fr ont Left Fr ont Left
SP-B
/ Zone 2 Left
SP-B
/ Zone 2 Left
Surr
ound Right
Surr
ound Right
Surr ound Bac
k
Right
Surr ound Bac
k
Right Zone 2 Right Zone 2 Right
Fr ont Left Fr ont Left SP-B
/ Zone 2
Left SP-B
/ Zone 2
Left
Fr ont Right Fr ont Right
SP-B
/ Zone 2 Right
SP-B
/ Zone 2 Right
Fr ont Right Fr ont Right SP-B
/ Zone 2
Right SP-B
/ Zone 2
Right Surr
ound
Right Surr
ound
Right
Center Center
Center Center
Surr
ound Left
Surr
ound Left
Surr
ound
Left Surr
ound
Left Surr ound Bac
k
Right Surr ound Bac
k
Right Zone 2 Right Zone 2 Right
Surr ound Bac
k Left
Surr ound Bac
k Left Zone 2 Left Zone 2 Left
Surr ound Bac
k
Left Surr ound Bac
k
Left Zone 2 Left Zone 2 Left
1 2
3
Speaker Cable
The alphabet displayed at the end of the product name found in catalogs and on the packages represents the color of this receiver.
Though the color varies, the specifications and operations are the same.
