Advanced Operations
En-62
• If you assign “- - - - -” to an input selector that is currently
selected in “HDMI Through” ( ➔ page 80 ), the “HDMI
Through” setting will be automatically switched to “Off”.
• “AUX” is used only for input from the front panel.
Component Video Input
If you connect a video component to a component video
input, you must assign that input to an input selector. For
example, if you connect your Blu-ray Disc/DVD player to
COMPONENT VIDEO IN 2, you must assign “IN2” to
the “BD/DVD” input selector.
If you’ve connected your TV to the AV receiver with a
component video cable, you can set the AV receiver so that
composite video source is upconverted
* and output by the
COMPONENT VIDEO MONITOR OUT *1 . You can set
this for each input selector by selecting the “- - - - -”
option.
*1 This applies only when “Monitor Out” setting is set to
“Analog” (
➔ page 60 ).
Here are the default assignments.
■ BD/DVD, CBL/SAT, STB/DVR, GAME1, GAME2,
PC, AUX, TV/CD, PHONO
` IN1, IN2:
Select the input to which the component has been
connected.
` - - - - -:
Output composite video sources from the HDMI
output.
Note
• For composite video upconversion for the COMPONENT
VIDEO MONITOR OUT, the “Monitor Out” setting must be
set to “Analog” (
➔ page 60 ), and the “Component Video
Input” setting must be set to “- - - - -”. See “Connection Tips and
Video Signal Path” for more information on video signal flow
and upconversion (
➔ page 107 ).
Input selector Default assignment
BD/DVD IN1
CBL/SAT IN2
STB/DVR - - - - -
GAME1 - - - - -
GAME2 - - - - -
PC - - - - -
AUX - - - - -
TV/CD - - - - -
PHONO - - - - -
IN
OUT
Composite video
Composite video
Component video
Component video
