2.2 Using Emulator with Connecting User System through User System
Interface Cable
CAUTION
When connecting or removing the user system interface
cable, apply force only in the direction suitable for
connection or removal, while making sure not to bend or
twist the cable or connectors.
Otherwise, the cables or connectors will be damaged.
1. Make sure that the emulator and the user system are turned off.
2. [1] After making sure the direction of the expansion I/O board connector (labeled E6000
EMULATOR) is correct, firmly insert the expansion I/O board connector into the emulator
station connector (labeled USER INTERFACE; [1] in figure 2.1).
[2] Connect the expansion I/O board (labeled USER INTERFACE CABLE) and the user
system interface cable body.
