1.4 Components
Figure 1.1 shows the HS36109EIO61H expansion I/O board appearance, and table 4 lists the
components of the expansion I/O board. Please make sure you have all of these components when
unpacking.
E6000
USER INT
ERFAC
E CABL
E
E600
0 EMULAT
OR
Figure 1.1 HS36109EIO61H Expansion I/O Board
Table 4 HS36109EIO61H Components
No. Component Quantity Remarks
1 HS36109EIO61H 1 Expansion I/O board
2 Documentation 1 User’s manual for HS36109EIO61H (this manual)
