Section 1 Overview
The H8/36109 group E6000 expansion I/O board (hereinafter referred to as the expansion I/O
board) is an efficient software and hardware development support tool for application systems
using timer RC, timer RD, SCI3, and AD converter (ports D to H are shared), which are dedicated
additional functions of the Renesas’ original microcomputer H8/36109 group.
The expansion I/O board should be used with H8/3664 series E6000 emulator station
(HS3664EPI61H or HS3664EPI62H; hereinafter referred to as the emulator).
1.1 Environment Conditions
Table 1 Environment Conditions
Item Specification
Temperature Operating: +10 to +35°C
Storage: –10 to +50°C
Humidity Operating: 35 to 80% RH; no condensation
Storage: 35 to 80% RH; no condensation
Ambient gases No corrosive gases
Power supply Power supply from E6000 emulator station
User system voltage (UVcc) Depends on the MCU within the range 3.0 V to 5.5 V
1.2 Supported MCUs and User System Interface Cable
Table 2 shows the correspondence between the MCUs and the user system interface cable
supported by the emulator.
Table 2 H8/36109 Group MCUs and User System Interface Cable
MCU Type Number Package E6000 User System Interface Cable
HD64F36109
HD64336109
HD64336108
HD64336107 100-pin QFP (FP-100A)
100-pin QFP (FP-100U)
HS36109ECF61H
HS36109ECH61H
