2. COLD FILM
1. Take out the guiding table.
2. Put the shaft of roll film in each hole exactly.
3. Set the pressure lever to the proper lamination mode.(1mm/5mm/10~13mm)
4. Pull the film around the idler bar to the Anti-wrinkle device.
5. Put the paper back of the film to the bobbin at take-up bar to rewind the paper back.
**It is to be stuck on to roll up clock wise.
6. Place the sticky part of film on the upper shoe and get ready to laminate.
PAPER BACK
TAKE UP DEVICE
HEAT SHOE
UPPER FILM SHAFT
COLD FILM
UPPER IDLE BAR
