Rollers do not operate 1. Power cord may not be plugged 1. Check the power cord
after press RUN in. 2. Check the switch is on
button. 2. Power switch is at OFF mode. 3. Check the emergency switch
3. Emergency switch may be at is off
ON mode. 4. Release STND-BY switch by
4. It may stay at STAND-BY mode. press the STND-BY button
Heat shoe is not 1. It is set at the cold mode 1. Change the function to hot
heater up. 2. Memorized temp may be lower lamination.
than atmosphere temp. 2. Set proper temperature for the
work
*Noise from friction 1. Film tension is too tight. 1. Adjust the film tension.
between the shoe 2. Temperature of heat shoe is too 2. Reduce the friction noise by
and film is loud, while high adjusting temperature on the
machine's operating heat shoes.
at a slow speed.
*Wrinkled lamination
1. Film tension is not proper, too 1. Adjust film tension.
result tight. 2. Put the Idle Bar at right position.
2. Idle Bar in line with lower roller
is not in proper position.
*Result of lamination is 1. Temperature on the heat shoe 1. Increase the temperature on the
not clear is too low or lamination is too heat shoe or decrease the
speedy. speed.
4. Bolt(M8X12) : 6EA
2. Fuse(50T) : 1EA 5. Washer-spring(Φ8) : 6EA
(AC 250V 6.3A)
3. Fuse(65TS) : 1EA
6. Bolt-core : 2EA
(AC250V 15A)
SPARE PARTS
It's not out of order
Cause Check point Symptom
1. Core(76mm) :6EA
- 25 -
