1. HOW TO CONTROL TENSION
2. HOW TO ADJUST ALIGNMENT
Location control device is used when the edges of the lamination are unjustified.
As the drawing shows, when the alignment knob is turned clockwise, the upper film is
to left. Once proper alignment is reached, turn the Locking Nut tight against the Alignment
knob so the adjustment is set.
ADJUSTMENT OF FILM TENSION AND LOCATIONS
can adjust it, to some extent, and make wrinkles straighten from Anti-Wrinkle Part of the
Tension of film can be controlled depending on the state of lamination, but basically you
heat shoe. To increase the tension on the film, turn the knob clockwise.
To lower the tension, turn the handle counter clockwise. If lamination is curved upward,
it means that tension of upper film is high. In this case, it can be controlled by raising
moved to right. On the contrary, when the handle is turned counter-clockwise, it is moved
apply the method in reverse.
tension of lower film or lowering tension of upper film. If lamination is curved downward,
Alignment Knob.
Locking Nut
Tension Control Knob
필 름
주 름 방 지 부
필 름
열 판
Film
Shoe-Heater
Film
Anti-Wrinkle
device
