Installation
18 Runco LS-HB Installation/Operation Manual
PRE
L
IMINAR
Y
Table 3-3 lists the available LS-HB lens options and their associated throw ratios.
Vertical and Horizontal
Position
Proper placement of the projector relative to the screen will yield a rectangular,
perfectly-centered image that completely fills the screen.
Ideally, the projector should be positioned perpendicular to the screen and in such a way
that the lens center is aligned with either the top or bottom edge of the screen area, and
centered horizontally. See Figure 3-3.
Table 3-3. LS-HB Lens Options and Throw Ratios (Note)
Projector Model
Throw
Ratio with
Primary
Lens Only
Throw Range in
inches, with
72.6x40.8-inch
(1.78:1) Screen
Throw Ratio
with
Primary
Lens and
Anamorphic
Lens
Throw Range in
inches, with
96x40.8-inch (2.35:1)
Screen
Minimum Maximum Minimum Maximum
LS-HB + Standard
Lens
1.89 – 2.40 137.21 174.24 (n/a)
LS-HB +
Standard Lens +
Fixed Anamorphic
Lens
(n/a) 1.89 – 2.40 181.44 230.40
LS-HB +
Standard Lens +
Movable
Anamorphic Lens
1.89 - 2.40 137.21 174.24 1.42 – 1.80 136.32 172.80
LS-HB + Optik A
Primary Lens
1.59 - 1.86 115.43 135.04 (n/a)
LS-HB + Optik A
Primary Lens +
Fixed Anamorphic
Lens
(n/a) 1.59 - 1.86 152.64 178.56
LS-HB + Optik A
Primary Lens +
Movable
Anamorphic Lens
1.59 - 1.86 115.43 135.04 1.19 - 1.40 114.24 134.40
Note: Due to normal manufacturing variances, throw distance can vary by up to +/- 5 percent from
these specifications.
➤
