Installing Options
74
F
Align the power cable to the left side groove of the duplex unit, and then
slide the duplex unit in until it is connected to the printer.
❒ After finishing installation, you can check the duplex unit is properly in-
stalled: Print the configuration page from the “List/Test Print” menu. If the
new device is listed in the column of configuration options, then it has been
properly installed.
❒ If the duplex unit is not installed properly, repeat the procedure from the
start. If you cannot install it properly even after reinstallation, contact your
sales or service representative.
❒ If the printing position is not correct, adjust the registration of the trays. For
more information about adjusting the registration of the trays, see “Adjust-
ing Tray Registration”, Maintenance Guide.
For printing the configuration page, see p.32 “Test Printing” .
