Installing Options
41
Attaching Envelope Feeder Type 610
❒ This unit is a tray that slides into the optional paper feed unit. Without the op-
tional paper feed unit, this envelope feeder cannot be used.
❒ Your printer can accommodate two optional paper feed units. The envelope
Feeder unit can be used in “Tray 2”. Neither the main unit's feed tray (Tray 1)
nor Tray 3 can be used for this purpose.
❒ Do not slide more than one paper tray out at the same time. Having more than
one full paper tray fully extended could cause the machine to topple.
The following explanation uses the example of installing the envelope feeder unit
in “Tray 2”.
A
Check the package contains the following:
❖ Envelope Feeder
B
Pull out the second paper tray (Tray 2) of the optional paper feed unit un-
til it stops. After that, lift it slightly, and then pull it out.
