Chapter 2. Introduction
This product is a PROM programming adapter for 7200 Series MCUs (8-bit MCU). This product is
used to write programs into the internal ROM of MCU with a commercially available PROM
programmer.
This manual mainly explains specifications of this product and how to operate it.
Figure 2.1 shows the external view of the product and its constituent parts.
Figure 2.1 External view of the adapter and its constituent parts
2.1 Things to Check When Unpacking
This product consists of the parts listed in Table 2.1. When unpacking, check to see that it contains
all of the components.
Table 2.1 Package components
Main unit
Connector
User's manual
PCA7408
PCA7402E (32-pin)
This user's manual
If any part is missing or there is any doubt about your product package, contact your local distributor.
PCA7408 R
EV.A
R1 R2
IC1
X1
16
JAPAN
C1
21
22
42
16
IC59-4206-G4
IC socket (made by Yamaichi ElectronicsCo., Ltd.)
PCA7408
Main unit
PCA7476E
PROM programmer connector
