Figure 3.1 Attaching the adapter to the PROM programmer
3.2 Attaching the Adapter to the PROM Programmer
As shown in Figure 3.1, attach the No. 1 pin of the PCA7402E connector (standard-pitch 32-pin pin-
header mounted) to the No. 1 pin of the IC socket of the PROM programmer.
Be careful when attaching to the PROM programmer because incorrect insertion
can cause fatal damage to the MCU.
32
1
1
6
1
7
PCA7408 REV.A
X1
16
JAPAN
C1
21
22
16
No. 1 pin of PCA7476E
No. 1 pin of IC socket
on the PROM programmer
