Chapter 4. Specifications
4.1 Specifications
Table 4.1 lists the common specifications of the programming adapter.
Table 3.1 Specifications
Applicable MCU
IC socket
Operating clock frequency
Power supply
M37221ERSS, M37221EFSP, M37221EFSS,
M37225ERSS, M37225ECSP, M37225ECSS
IC59-4206-G4 (made by Yamaichi Electronics Co., Ltd.)
4 MHz
(Supplied by the ceramic oscillator mounted on the PCA7408)
Supplied from the Vcc of the PROM programmer
A programmable MCU mounted
(IC socket for MCU mounted)
Board to be connected to the PROM programmer (for 1M bit mode)
(Standard-pitch 32-pin pin-header to be connected to the PROM
programmer mounted)
Board
configuration
PCA7408
PCA7402E
CAUTION
Note on the Latest MCU Information:
• For the latest information about the applicable MCUs, visit Renesas Tools Home-
page.
http://www.renesas.com/jp/tools
