RS12 GPS Sensor

Approvals

CE - conforms to

1999/5/EC

Dimensions:

diameter: 3.7 in (95 mm)

height: 1.2 in (30 mm); 2.4 in (62 mm) with pole mount

kit

Weight:

15.3 oz (0.435 kg)

Cable length:

33 ft (10 m)

Receiver type:

SD-GPS, WAAS/EGNOS/MSAS ready, 12 parallel chan-

nels

Operating conditions:

temperature range: 14°F to 158°F (–10°C to 70°C)

water protection: waterproof to CFR46

Storage conditions

temperature range: 14°F to 158°F (–10°C to 70°C)

Frequency

1575.42 MHz ±1 MHz (C/A code), L1

Sensitivity

Tracking: –152 dBm

Acquisition: –139 dBm

Signal acquisition:

Automatic

Time to first fix (TTTF):

Hot start < 6 seconds (typical);

Warm start < 40 seconds (typical);

Cold start < 60 seconds (typical)

Position accuracy:

2 DRMS ~ 2 m 95%

Speed accuracy:

0.1 kts RMS

Geodetic datum:

WGS-84
