63
MIDI Implementation
Appendices
❍ Exclusive Address Table Recording setting (Replacement Recording)
Address(H) SIZE(H) DATA(H) Parameter Description
===================================================================
00 01 10
00 00 08 00 - 07 Phrase Number upper 4bits
11# 00 - 7f Phrase Number lower 7bits
12# 00 - 04 Grade 0:ANNOUNCE
1:LONG2
2:LONG1
3:STANDARD
4:HIGH
5:S-HIGH
13# 00 - 02 R-DAC mode 0:Linear
1:Mode1
2:Mode2
3:Mode3
4:H-Linear
14# 00 - 01 REC type 0:MONO
1:STEREO
15# 00 - 03 REC Trigger Level 0:OFF
1:LOW
2:MID
3:HIGH
16# 00 - 02 REC Source 0:ANALOG-IN
1:DIGITAL-IN
2:MIDI-IN
17# 00 - 01 TimeBase 0:192
1:240
===================================================================
Phrase number DATA(H)
A0001 - A1000 00 00 - 07 67
B0001 - B1000 07 68 - 0F 4F
* Only received packet data.
* When reception of this packet is completed, the AR-3000 goes into REC PAUSE mode.
However, if a phrase has already been saved, the AR-3000 deletes that phrase and goes
into REC PAUSE mode.
(AR-2000 compatible)
Address(H)
SIZE(H) DATA(H) Parameter Description
===================================================================
00 01 00
00 00 08 00 - 07 Phrase Number upper 3bits
01# 00 - 7f Phrase Number lower 7bits
02# 00 - 04 Grade 0:ANNOUNCE
1:LONG2
2:LONG1
3:STANDARD
4:HIGH
03# 00 - 02 R-DAC mode 0:Linear
1:Mode1
2:Mode2
04# 00 - 01 REC type 0:MONO
1:STEREO
05# 00 - 03 REC Trigger Level 0:OFF
1:LOW
2:MID
3:HIGH
06# 00 - 01 REC Source 0:ANALOG-IN
(MIDI REC OFF)
1:MIDI-IN
(MIDI REC ON)
07# 00 - 01 TimeBase 0:192
1:240
===================================================================
Phrase number DATA(H)
A0001 - A0500 00 00 - 03 73
B0001 - B0500 03 74 - 07 67
* Only received packet data.
* When reception of this packet is completed, the AR-3000 goes into REC PAUSE mode.
However, if a phrase has already been saved, the AR-3000 deletes that phrase and goes
into REC PAUSE mode.
❍ Exclusive Address Table Phrase Select AR-200/3000
Address(H) SIZE(H) DATA(H) Parameter Description
===================================================================
01 00 10
00 00 02 00 - 07 Phrase Number upper 4bits
11#‘ 00 - 7f Phrase Number lower 7bits
===================================================================
Phrase number DATA(H)
A0001 - A1000 00 00 - 07 67 (AR-200/AR-3000)
B0001 - B1000 07 68 - 0F 4F (AR-3000)
* Only received packet data.
* V
(AR-100/2000 compatible)
Address(H)
SIZE(H) DATA(H) Parameter Description
===================================================================
01 00 00
00 00 02 00 - 07 Phrase Number upper 3bits
01# 00 - 7f Phrase Number lower 7bits
===================================================================
Phrase number DATA(H)
A0001 - A0500 00 00 - 03 73 (AR-200/AR-3000)
B0001 - B0500 03 74 - 07 67 (AR-3000)
* Only received packet data.
* When reception of this packet is completed, the AR-200/3000 changes to the current
(currently displayed) phrase number.
❍ Exclusive Address Table Recording Settings AR-200/3000
Address(H) SIZE(H) DATA(H) Parameter Description
===================================================================
01 00 10
00 00 03 00 - 07 Phrase Number upper 4bits
11# 00 - 7f Phrase Number lower 7bits
12# 00 - 02 REC Source 0:ANALOG-IN
1:DIGITAL-IN
2:MIDI-IN
===================================================================
Phrase number DATA(H)
A0001 - A1000 00 00 - 07 67 (AR-200/AR-3000)
B0001 - B1000 07 68 - 0F 4F (AR-3000)
* Only received packet data.
* When reception of this packet is completed, the AR-3000 goes into REC PAUSE mode.
However, if a phrase has already been saved, the AR-3000 deletes that phrase and goes
into REC PAUSE mode.
(AR-100/2000 compatible)
Address(H)
SIZE(H) DATA(H) Parameter Description
===================================================================
01 00 00
00 00 03 00 - 07 Phrase Number upper 3bits
01# 00 - 7f Phrase Number lower 7bits
02# 00 - 02 REC Source 0:ANALOG-IN
(MIDI REC OFF)
1:MIDI-IN
(MIDI REC ON)
===================================================================
Phrase number DATA(H)
A0001 - A0500 00 00 - 03 73 (AR-200/AR-3000)
B0001 - B0500 03 74 - 07 67 (AR-3000)
* Only received packet data.
* When reception of this packet is completed, the AR-3000 goes into REC PAUSE mode.
However, if a phrase has already been saved, the AR-3000 deletes that phrase and goes
into REC PAUSE mode.
