54
Appendices
Recorded Phrase Data
When a piece of Phrase data recorded by the AR-200, the set-
tings of data on the card will be as follows.
If you will be using the card on the AR-3000, refer to this list.
Phrase settings
Playback Volume: 100
Delay time: OFF
Playback point:
• start: 00h00m00s00f00f0sf
• End: The real time of the phrase
Repeat playback: OFF
Loop playback: OFF
fade:
• fade in: OFF
• fade out: OFF
Control output: OFF
MIDI playback time: 120
Phrase name: MESSAGE1
(MESSAGE + Phrase number)
Settings When a Card Is
Formatted
When a card is formatted by the AR-200, the settings of the
card will be as follows.
If you will be using the card on the AR-3000, refer to this list.
Recording settings
• Recording jack select: LINE-IN
• RDAC-GRADE: STANDARD
• Recording type: Stereo
• Trigger recording: OFF
• MIDI Time base: 192 (MIDI phrase only)
Phrase messages
Playback Volume: 100
Delay time: 00s00f
Playback point:
• start: 00h00m00s00f0sf
• End: The real time of the phrase
Repeat playback: OFF
Loop playback: OFF
fade:
• fade in: OFF
• fade out: OFF
Control output: OFF
MIDI playback tempo: 120
Phrase name: MESSAGE1
(MESSAGE + Phrase number)
Card Edit
Card protect: OFF
card name: MESSAGE
Control input settings
control input MODE: DIRECT
Direct playback method: Normal
• phrase assign
Port No. Phrase
1 A0001
2 A0002
3 A0003
4 A0004
5 A0005
6 A0006
7 A0007
8 A0008
9 A0009
10 A0010
11 A0011
12 A0012
13 A0013
14 A0014
15 A0015
16 A0016
Program Playback
Program 1 played back in order
No. 1: Phrase A0001
↓
No.100: Phrase A0100
Programs 2 through 5 played back in order
No. 1: Phrase ----
↓
No.100: Phrase ----
Binary playback
• Level: ON
• Edge: OFF
Terminal Rec
• Phrase specify:Binary1
