73
MIDI Implementation
●
Note On
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
kk = note number: 23H - 72H (35 - 114)
vv = note on velocity: 01H - 7FH (1 - 127)
● Control Change
❍ CTRL1 (Controller number 13)
Status 2nd byte 3rd byte
BnH 0DH vvH
n = MIDI channel number: 0H - EH (ch.1 - ch.15)
vv = Control value: 00H - 7FH (0 - 127)
❍ CTRL2 (Controller number 14)
Status 2nd byte 3rd byte
BnH 0EH vvH
n = MIDI channel number: 0H - EH (ch.1 - ch.15)
vv = Control value: 00H - 7FH (0 - 127)
❍ CTRL3 (Controller number 15)
Status 2nd byte 3rd byte
BnH 0FH vvH
n = MIDI channel number: 0H - EH (ch.1 - ch.15)
vv = Control value: 00H - 7FH (0 - 127)
■ System Realtime Message
●
Timing Clock
Status
F8H
* This message is transmitted only if Tx MIDI Sync is ON.
● Start
Status
FAH
* This message is transmitted only if Tx MIDI Sync is ON.
● Continue
Status
FBH
* This message is transmitted only if Tx MIDI Sync is ON.
●
Stop
Status
FCH
* This message is transmitted only if Tx MIDI Sync is ON.
●
Active Sensing
Status
FEH
