44

Runco CL-610 Owner’s Operating Manual

On-Screen Display Menus

ICC Adjust

Use the ICC Adjust controls to customize the stored NTSC,
HDTV and/or PAL color characteristics. To do this, select
the color space to modify. Then, select a component color
(Red, Green, Blue, Yellow, Cyan or Magenta).
For each component color, you can adjust the following:
Intensity: This slidebar adjusts the intensity -- also known
as luminance -- of a given color.
Sat.: This slidebar adjusts the color saturation level -- the
amount of that color in a video image. Lower settings
produce less saturated colors; a setting of “0” removes that
color from the image entirely. If the saturation is too high,
that color will be overpowering and unrealistic.
Hue: This slidebar adjusts the red/green color hue for true
color reproduction of video signals. For best results, adjust
tint while displaying an external color bars test pattern.
Otherwise, it is recommended that Hue remain at its default
setting.
When you have finished customizing the color space, select
Store Setting and press Enter.

When you have finished calibration, select

Store Image

Settings and choose “Memory 1,” “ISF Night“ or “ISF Day”
to store your settings.
To recall stored custom image quality settings, select
Restore Image Settings from the Adjustment menu (refer
to “Picture Quality Adjustments,” earlier in this section) and
choose “Memory 1,” “ISF Night“ or “ISF Day.” Or, simply use
the corresponding buttons on the remote control.

Press the

◄ or ► arrows to set the Splash Screen Timer.

This timer controls how long the startup (ISF and Runco
logo) image stays on-screen after you turn on the projector.
Select from 5 to 60 seconds, in 1-second increments. When
finished, press

Exit.

Use

ISF Enable to control the display of the ISF logo on

the CL-610 splash screen upon power-up.

Store Settings

Splash Screen Timer

ISF Enable

ICC Adjust

Color

NTSC

R G B Y C M
Intensity

+100

Sat.

+100

Hue M

C 0

Store Setting

Store Settings

Memory 1

ISF Night

ISF Day

Splash Screen Timer

+20 - +

ISF Enable

> Off

On
