29

Runco CL-610 Owner’s Operating Manual

Setting the Menu

INFO

RVR

ENTER

EXIT

MENU

• Press

INFO to view information about the

active signal source and aspect ratio.

• Press

MENU to open or close the on-screen

menu.

• Use the arrow buttons (

▲,◄,▼,►) to select

menu items or make adjustments.

• Press

ENTER or

► to enter the setting of

items in the menu, or press

EXIT to leave

and save the setting of items in the menu.

For more information
on settings, See “On-
Screen Display Menus”
on page 31.

Basic Operation

Selecting the Input
Source

PIP / PBP Function

VID

S-VID

COMP1

RGBHD

HDMI

COMP2

PBP

PIP

PIP+

ACT

PIP-

• When you turn on the projector, it searches

for the input source you selected last
time.

• You may select the input source directly

on the remote control.

• For PIP (Picture In Picture) and PBP (Picture

By Picture) purposes, there are two groups
of inputs separated by their display modes:

Video group: Video, S-Video and
Component Y/C

B

/C

R

inputs.

Graphic (HD) group: HDMI and RGB/
Component HD inputs.

• PIP / PBP shows one input from the

Graphic group within or beside one input
from the Video group.

• Press

PBP to enable the PBP function.

Press

PBP again to switch the screens

left to right. Press

PBP again to turn PBP

off.

• Press

ACT (Active) to switch to the active

window. You can only change the input
signal settings in the active window.

• Press

PIP to enable the PIP function.

Press PIP again to switch the main window.
Press PIP again to turn PIP off.

• Press

PIP+ or PIP- to adjust the size of

the PIP window.

• Adjust the position of the PIP window with

the ARROW keys (

▲,◄,▼,►).
