Specifications

M-16DX

M-10DX

M-10MX

Number of Input Channels

16 channels

10 channels

10 channels

AD/DA Conversion

Sample Rate: 44.1/48.0/96.0 kHz

Signal Processing: 24 bits

96.0 kHz: 20 Hz to 40 kHz (+3/-3 dB), 48.0 kHz: 20 Hz to

22 kHz (+3/-3 dB), 44.1 kHz: 20 Hz to 20 kHz (+3/-3 dB)

Sample Rate: 44.1/48.0/96.0 kHz,

Signal Processing: 24 bits

Frequency Response

96.0 kHz: 20 Hz to 40 kHz (+3/-3 dB), 48.0 kHz: 20 Hz to

22 kHz (+3/-3 dB), 44.1 kHz: 20 Hz to 20 kHz (+3/-3 dB)

96.0 kHz: 20 Hz to 40 kHz (+1/-2 dB), 48.0 kHz: 20 Hz to

22 kHz (+1/-2 dB), 44.1 kHz: 20 Hz to 20 kHz (+1/-2 dB)

Residual Noise Level

(IHF-A, typ.)

MAIN MIX LEVEL knob = -∞, Channel LEVEL knobs =

-∞, MAIN MIX LEVEL knob = U, Channel LEVEL knobs =

-∞: -96 dBu, MAIN MIX LEVEL knob = U, Channel LEVEL

knobs = U: -83 dBu

MAIN MIX LEVEL knob = -∞, Channel LEVEL knobs =

-∞, MAIN MIX LEVEL knob = U, Channel LEVEL knobs =

-∞: -88 dBu, MAIN MIX LEVEL knob = U, Channel LEVEL

knobs = U: -82 dBu

-86 dBu

Nominal Input Level

MIC connectors 1–4: -60 to -10 dBu, LINE IN jacks 1–4:

-40 to +10 dBu, * Maximum input level: Nominal input

level + 22 dB, LINE IN jacks 5–16: +0 dBu, LINE IN jacks

15–16 (RCA pin type, Stereo miniature phone type):

-10 dBu, * Maximum input level: Nominal input level

+ 18 dB

MIC connectors 1–2: -60 to -10 dBu, LINE IN jacks 1–2:

-40 to +10 dBu, * Maximum input level: Nominal input

level + 22 dB, LINE IN jacks 3–10: +0 dBu, LINE IN jacks

9–10 (RCA pin type): -10 dBu, * Maximum input level:

Nominal input level + 18 dB

Input Jacks 1–6: -50 to +4 dBu

Input Jacks 1–2: -40 to +10 dBu

Input Jacks 5–10: -2 dBu

* Maximum input level: Nominal input level + 12 dB

Input Impedance

MIC connectors 1–4: 1.5 kΩ, LINE IN jacks 1–4: 20 kΩ,

LINE IN jacks 5–16: 20 kΩ, LINE IN jacks 15–16 (Stereo

miniature phone type): 14 kΩ

MIC connectors 1–2: 2.7 kΩ, LINE IN jacks 1–2: 28 kΩ,

LINE IN jacks 3–8: 20 kΩ, LINE IN jacks 9–10 (RCA pin

type): 20 kΩ

Nominal Output Level

MAIN OUT jacks/ALT OUT jacks/AUX SEND jacks 1–2: +0

dBu, 2 TRACK OUT jacks L–R: -10 dBu, CONTROL ROOM

jacks: -6 dBu, * Maximum output level: Nominal Output

Level + 22 dB

+0 dBu

* Maximum output level: Nominal Output Level + 22 dB

-2 dBu

* Maximum output level: +10 dBu

Output Impedance

MAIN OUT jacks/ALT OUT jacks/AUX SEND jacks 1–2:

600 Ω, 2 TRACK OUT jacks L–R: 1 kΩ

Recommended Load

Impedance

10 kΩ or greater

10 kΩ or greater

Display

Graphic LCD 122 x 32 dot (with back-light)

Graphic LCD 122 x 32 dot (with back-light)

Connectos

(I/O module)

MIC connectors 1–4: XLR type (balanced / phantom

power +48 V), LINE IN jacks 1–14: 1/4 inch TRS phone

type (balanced), * LINE IN jacks 1–2: supports use of

hi-impedance, LINE IN jacks 15–16: RCA pin type, MAIN

OUT jacks L–R: 1/4 inch TRS phone type (balanced), ALT

OUT jack L–R: 1/4 inch TRS phone type (balanced), AUX

SEND jacks 1–2: 1/4 inch TRS phone type (balanced),

2 TRACK OUT jack L–R: RCA pin type, DIGITAL INPUT

jack/connector: Optical type, Coaxial type, DIGITAL

OUTPUT jack/connector: Optical type, Coaxial type, USB

Connector, DX BUS Connector: D-SUB 15 pin

(MIX controller)

LINE IN jacks 15–16: 1/4 inch phone type (unbalanced),

Stereo miniature phone type, PHONES jack: Stereo 1/4

inch phone type, CONTROL ROOM jacks L–R: 1/4 inch

phone type (Impedance balanced), DX BUS Connector:

D-SUB 15 pin

MIC connectors 1–2: XLR type (balanced / phantom

power +48 V), LINE IN jacks 1–10: 1/4 inch TRS phone

type (balanced), * LINE IN jack 1: supports use of hi-

impedance, LINE IN jacks 9–10: RCA pin type, MAIN

OUT jacks L–R: 1/4 inch TRS phone type (impedance

balanced), AUX SEND jack: 1/4 inch TRS phone type

(impedance balanced), 2 TRACK OUT jacks L–R: RCA pin

type, DIGITAL OUTPUT jack/connector: Optical type,

Coaxial type, PHONES jack: Stereo 1/4 inch phone type,

CTRL ROOM jacks L–R: 1/4 inch phone type (impedance

balanced)

Input Jacks 1–6: 1/4 inch phone type, unbalanced, Input

Jacks 1–2: Stereo miniature type, plug-in powered),

Input Jacks 5–10: RCA pin type, Main Output Jacks

L, R: 1/4 inch TRS phone type (impedance balanced),

RCA pin type, Digital Output Connectors: Optical type,

Coaxial type, Headphone Jack: Stereo miniature type,

DC IN (AC adaptor) Jack

DSP processing

Room Acoustic Control (Built-in Microphone), 16 Band

Graphic EQ, Finalize: Enhancer/Multi-band Compressor-

Limiter, Insertion effects: Power compressor/Vocal

enhancer/Narration enhancer, Echo/Reverb: Short echo/

Echo/Room reverb/Small hall reverb/Large hall reverb

Room Acoustic Control (built-in microphone), Finalize:

Enhancer/Multi-band Compressor-Limiter, Insertion

effects: Power compressor/Vocal enhancer/Narration

enhancer, Echo/Reverb: Short echo/Echo/Room reverb/

Small hall reverb/Large hall reverb

Number of USB Audio Record/

Playback Channels

Record: 18 channels, Playback: 2 channels, Full duplex,

* When using the mixer as a USB audio interface, the

Finalize effects are not available in 96 kHz mode.

Power Supply

DC 9 V (AC adaptor)

DC 9 V (AC adaptor), Alkaline dry battery LR6 (AA) type

x 8 or Nickel metal-hydride battery (HR15/51) x 8

DC 9 V (AC adaptor), Alkaline dry battery LR6 (AA)

type x 4

Current Draw

1.4 A

950 mA, * Expected battery life under continuous

use: Nickel metal-hydride: 3 hours, Alkaline: 1.5–2

hours, These figures will vary depending on the actual

conditions of use.

250 mA * Expected battery life under continuous use:

Alkaline: 6 hours (Power save mode: On), 4 hours (Power

save mode: Off ), These figures will vary depending on

the actual conditions of use.

Phantom Power

+48 V/5 mA (each input)

+48 V/5 mA (each input)

Accessories

Owner’s manual, Read this first/M-16DX driver

installation (driver installation manual), Controller cable

(D-SUB 15 pin, 2 m), USB cable, Driver CD-ROM, SONAR

LE CD-ROM, AC Adaptor, Rack-mount adaptor, Rubber

feet (I/O module), Roland software license agreement

Owner’s manual, AC adaptor

Owner’s Manual, AC Adaptor, Ferrite Core

Option

Controller cable: DXC-7 (D-SUB 15 pin, 7 m)

Size and Weight

(I/O module)

280 (W) x 219 (D) x 44 (H) mm

11-1/16 (W) x 8-5/8 (D) x 1-3/4 (H) inches

1.6 kg, 3 lbs. 9 oz.

(MIX Controller)

311 (W) x 216 (D) x 46 (H) mm

12-1/4 (W) x 8-1/2 (D) x 1-13/16 (H) inches

1.2 kg, 2 lbs. 11 oz.

199 (W) x 262 (D) x 61 (H) mm

7-7/8 (W) x 10-3/8 (D) x 2-7/16 (H) inches

1.3 kg, 2 lbs. 14 oz.

181.2 (W) x 107.5 (D) x 54.0 (H) mm

7-3/16 (W) x 4-1/4 (D) x 2-1/8 (H) inches

393 g, 14 oz

M-16DX

* Please remember that multitrack

recording at higher bit rate and

sampling frequencies may require

large amounts of free disk space

and fast hard drives.

* This product has been tested on

representative computers that

meet the system requirements,

but we cannot guarantee that it

will operate on every computer

that meets these requirements.

Please be aware that even under

the same conditions, differences

in the operating environment may

produce differences in processing

capability.

System Requirements [Windows]
Operating System

Microsoft® Windows® XP Home Edition Service Pack 2, Microsoft® Windows® XP Professional Service Pack 2, Microsoft® Windows Vista™

* This does not work with the 64-bit Edition of Windows Vista™.

Computer

Windows XP or Windows Vista compatible computer with a USB connector that supports USB Specification Revision 2.0 or higher

* Intel chipset is recommended.

* M-16DX’s USB Audio Interface may not perform to its full specs when used with Celeron or Intel compatible processors.

* When using an added USB 2.0 interface card, such as a PCI card, “NEC PCI to USB Enhanced Host Controller” is recommended.

CPU/Clock

Pentium 4 Processor / 1.6 GHz r higher, Pentium M Processor / 1.3 GHz or higher

Memory (RAM)

512 MB or more * In case of Windows Vista, 1 GB RAM or more is recommended.

System Requirements [Macintosh]
Operating System

Mac OS X v10.4.3 or later

* The driver can work on both Intel processors and PowerPC processors (Universal Binary).

* This will not operate in the Classic environment of Mac OS X. When using this, the Classic environment must not be running simultaneously.

Computer

Apple Macintosh series computer with on-board USB 2.0

Please contact EDIROL distributor in your country,

or visit us online at www.EDIROL.net

All specifications and appearances are subject to change without change.

All trademarks are the property of their respective companies.

Printed in Japan Apr. 2007 RAM-4206 EC2-YF-NK
