Page 69

Text mode
Original mode

Loading A Roll Of Paper

Note

❒ Do not hold the paper knob from side. It may cause you touching a sticky

oil. For how to turn the knob without any harm, see the illustration below:

❒ Make sure that the paper is not loose. Insert it straight into the roller.
❒ Watch carefully to make sure that the flap of the paper is inserted between

feeder and the roller.

❒ For how to change the Roll 2, refer to the following illustration:

Hold the paper (

B ), and then slide the cutter (A

A).

Note

❒ Slide the cutter one way only, otherwise paper waste may pile up inside

the machine.

Turn the knob anticlockwise about 1/4 to adjust the paper position.
