Maintaining Your Copier

Loading A Roll Of Paper

When

C is displayed, it is time to install a new roll of paper.

CAUTION:

Important

❒ When removing paper rolls, lift the roll holders on both sides of the paper roll

before removing it. Do not lift one side only. This could damage the machine.

Pull out the Roll Feeder.

Hold both sides of the empty paper roll and remove it from the unit.

• Rolls of paper can be heavy, so you should be careful when load-

ing one.

• Be careful when replacing the roll paper or removing misfed pa-

per by following the operating instructions properly. Otherwise,
an injury may result from the paper cutter inside.

• Do not touch the anti-humidity switch from inside the machine. It

could be very hot.

ZEDH390E
