25 Regency ® E21-3 Gas Fireplace Insert
6) Place Bottom Frame near hinge. Flip hinge over Bottom Frame and
secure with 3 screws each.
Bottom Frame
Hinge Location
5) Install Spring Hinges to the Left and Right Side of the bottom of the
fi rebox using 2 screws per hinge.
7) Install the Left and Right Side Screen Doors by placing over top of
the hinges on the faceplate.
Hold the door at a 45 degree angle to avoid scratching the
faceplate.
Hinge
Screen Door
8) Close screen doors.
INSTALLATION
