19 Regency ® E21-3 Gas Fireplace Insert
FLUSH GLASS
1) Install the bottom glass trim onto the glass
support.
2) Slide the glass into the bottom glass trim
and secure with the glass clips using the 2
phillips head screws at the top.
3) Slide the top glass trim by sliding under the
two spring clips.
Note: To re-install the glass, reverse the
procedure.
WARNING
The use of substitute glass will
void all product warranties.
Do not operate the appliance if the
glass panel(s) are removed, cracked
or broken. Replacement of the glass
panel(s) should be done by a qualifi ed
service person.
FLUSH LOUVERS
1) The Top Louver is held in place by Spring
Clips. Push into place as shown.
2) Install the Spring Hinges on the left and right
side of the bottom of the Firebox using 2
screws per hinge.
3) Place the Bottom Louver near the hinge. Flip
hinge over the Bottom Louver and secure
using 3 screws.
Bottom Louver
Hinge
Location
INSTALLATION
