15 Regency ® E21-3 Gas Fireplace Insert
6) Fit log 27-26 into the pins on the front right side of the burner.
5) Rest the top of log 27-25 in the notch in log 27-24 and rest the bottom
end of log 27-25 on the fi rebox base.
7) Fit the top end of log 27-27 into the pin in log 27-23 and rest the
bottom end of log 27-27 against the 2nd grate post.
2nd Grate Post
27-24
27-25
27-25
27-26
27-26
27-27
27-23
27-27
INSTALLATION
