Note: Adjust VOLUME to the middle po-
sition before connecting power.
Caution: The supplied adapter sup-
plies 9 volts AC, delivers at least 440
milliamps, and has a plug which proper-
ly fits the TAD-1028’s
AC 9V 440mA
jack. Using an adapter that does not
meet these specifications might dam-
age the TAD or the adapter.
On a Desk Top
Follow these steps when you place the
TAD on a desk, shelf, or table.
1. Plug one end of the supplied long
modular cord into the TO LINE jack
on the back of the base.
2. Plug the modular cord’s other end
into a modular phone line jack.
3. Plug one end of the supplied coiled
handset cord into the jack on the
bottom of the base. Plug the other
end into the handset’s jack.
4. Place the handset in the cradle.
5. Insert the supplied AC adapter’s
barrel plug into the AC 9V 440mA
jack on the back of the base.
6. Route the adapter’s cord through
the strain relief slot on the base.
7. Plug the adapter into a standard
AC outlet.
Illus. of VOLUME
switch.
Illus. of TO LINE jack
and end of modular
inserted into jack.
cord about to be
Other connections
are not yet made.
Illus. showing
connection of
coiled cord.
Illus. of AC 9V 440mA
jack. Show barrel
inserted into jack.
plug about to be
Show modular cord
already connected.
Illus. showing cord
routed through the
strain relief slot.
