Rinnai CONTINUUM 2424WC - Manual (Page 43)

Model 2424WC 800-621-9419 4 3
I N S TA L L E R ’ S I N S TA L L AT I O N I N S T R U C T I O N S
Parts List
001
004
007
012
016
017
018
019
022
023
100
101
103
104
104
106
107
110
111
112
113
114
115
Number Description
Casing Assembly
Heat Protection Plate
Front Panel Assembly
Wall Installation Bracket
Front Panel Packing
Front Panel Packing - Side
Connection Reinforcement Panel
Gas Control Bracket
Cable Connection
Cable Seal Packing
Gas Connection (3/4” NPT)B
Test Point Screw
Gas Control Assembly
Manifold Assembly - A (LPG)
Manifold Assembly - B (Nat)
Burner Case Front
Sound Proofing Panel
Side Type Sleeve Burner Assembly
Burner Case Back Panel
Comb. Chamber Front Panel
(Complete Assembly)
Comb, Chamber Front Panel (Assy)
Upper Packing - Comb. Chamber
Lower Packing - Comb. Chamber
Part Number
DU195-100-2
BU155-110
DU195-1615-2
BU195-121
BU195-167
AU115-163
BU169-120
BU169-125
BU56-602-N
AU169-126
CU195-211-2
C10D-5
C36E-30-S
CU195-200-A
CU195-200-B
DU195-255
CU169-257
B3A1-4
CU169-256
CU195-920
CU195-310
BU195-315
BU195-316
Quantity
1
1
1
2
1
2
1
1
1
1
1
2
1
1
1
1
1
18
1
1
1
1
1
