– 28 –
I
N
S
T
A
L
L
A
T
I
O
N
® ®
• Gain Control for channels A & B set equally
• Gain Control for channel C operates independently
• Impedance Load for bridged left channel should be 4
Ω
minimum
• Impedance Load for bridged right channel should be 4
Ω
minimum
• Impedance Load for stereo channel C should be 2
Ω
minimum
• XCards A & B set identically as 12dB High-Pass, 12dB Low-Pass or
Full Range
• XCard C can be set for High-Pass, Low-Pass or Full Range
4-Channel Stereo Operation
Ch. A Ch. A Ch. B Ch. B
REM Dual B+ Dual GND – L + + L – – R + + R –
Left
– +
4 ohm min.
Right
+ –
+ –
LED
Ch. C
Bass EQ
Ch. C
Gain
Ch. C Ch. B Ch. A
Ch. B
Gain
Ch. A
Gain L
R
L
R
L
R
Ch. C
Ch. C
4 ohm min.
+ L –
2 ohm min.
+ –
2 ohm min.
+ R –
