9

5. Plug the adapter into a standard AC

outlet.

6. Lift the base’s antenna to a vertical

position.

On a Wall Plate or Wall

1. Insert the two tabs at the top of the

narrow end of the supplied bracket
into the base’s upper tab slots as
shown, then press down on the
bracket’s latches and insert them in-
to the lower slots.

2. Plug one end of the supplied short

modular cord into the

TEL LINE

jack

on the back of the base as in “On a
Desk Top,” Step 1, on Page 8.

3. Insert the supplied AC adapter’s

barrel plug into the

DC IN 9V

jack as

in “On a Desk Top,” Step 3, on Page
8.

4. Route the adapter and modular

cords through the grooves on the
bracket.

5. Plug the modular cord’s other end

into the wall plate jack, then align
the bracket’s keyhole slots with the
wall plate studs and slide the base
downward to secure it.

6. Plug the adapter into a standard AC

outlet.

7. Press and lift out the handset hold-

er, flip it over as shown, then snap it
back into place so it holds the hand-
set.
