28
Intercom Key Operation
Basic Intercom Key Operation
Coupled with the traditional operation of keys, the KP 32 CLD keypanel also has an integrated LCP (level control panel). This
feature allows the user to adjust the volume for individual keys on the keypanel. Figure 14 displays the different key positions
and their meanings.
Ver
Displays the firmware version currently loaded on the KP 32 CLD. For more information, see
“Display Menu, Version” on page 85.
FIGURE 14. KP 32 CLD Key Position Explanation
TABLE 4. INFO Button Feature and Option Descriptions
