Vertical – Raymarine DSM30 User Manual
Page 12
12
DSM300 and DSM30 Installation Manual
To mount the DSM:
1. Hold the module
in the location where you want to mount it, making sure it is
perpendicular to the deck.
2. Mark the location of the four key holes onto the mounting surface.
3. Drill a 9/64" pilot hole at each of the marked locations.
Vertical
x4
D7479-1
Vertical
x4
D7538-1
