4. Route the adapter cord through the
narrow groove on the bracket. If you
are using two phone cords, route
the second cord through one of the
wide grooves on the bracket.
5. Plug the other end of the short mod-
ular cord into the wall plate jack,
then align the bracket’s keyhole
slots with the wall plate studs and
slide the base downward to secure
it. If you are using two phone cords,
plug the second cord into the sec-
ond phone jack.
6. Plug the adapter into a standard AC
outlet.
7. Press and lift out the handset
holder, flip it over as shown, then
snap it back into place.
8. Lift the base’s antenna to a vertical
position.
Directly on a Wall
To mount the base directly on the wall,
you need two screws (not supplied) with
heads that fit into the keyhole slots on the
bottom of the base.
1. Drill two holes 3
15
/
16
inches (100 mm)
apart. Then thread a
screw into each hole,
letting the heads ex-
tend about
5
/
16
inch (8
mm) from the wall.
Narrow
Groove
Wide
Grooves
5
/
16
"
3
15
/
16
"
