- 3 -
Specifi cations
Acoustic Principle: Permanently Polarised
Condenser
Directional
Pattern: Cardioid
Frequency Range: 40Hz ~ 20,000Hz
selectable High Pass Filter (HPF)
@ 80Hz 12dB/octave (see graph)
Output
Impedence: 200Ω
Sensitivity: -40dB ±3dB re 1V/Pa @ 1kHz
(6.3mV/Pa @ 94dB SPL)
Equivalent Noise: 21dBA SPL
(A - weighted per IEC651)
Maximum Output: +9.22dBu (@ 1% THD into 1kΩ)
Dynamic Range: 121dB (per IEC651)
Maximum SPL: 142dB (@ 1kHz, 1% THD into
1kΩ load)
Signal/Noise: 73dB SPL (@ 1kHz, rel 1Pa)
Power
Requirements: 1.6mA - battery
6.5mA - 48V Phantom Power
Battery Life: >200 hours
Output
Connection: 3 pin XLR, balanced output
between Pin 2 (+), Pin 3 (-) and
Pin 1 (ground)
Net Weight: 390g (no battery)
Shipping Weight: 1,285g
Dimensions: Length - 225mm (8 3/4 ”)
Diameter - Ø33mm (1 5/16 ”)
