- 10 -
L.E.D. SINGLE FLASH – When the L.E.D. fl ashes
(illuminates for around one second), the battery power
is ‘good’. This indicates that the microphone has just
been powered.
L.E.D. STAYS ON – When the L.E.D. light illuminates
continuously the battery power is getting low. Please
replace the battery as soon as possible, as the
microphone’s sensitivity is greatly compromised when
operated with a low battery.
Note: When using M3 on battery power, it is a good
idea to keep the microphone in the off position when
not in use. This will save battery power and increase
the battery life. We recommend that during long
periods of non-use the battery should be removed, as
it may leak and potentially damage the microphone.
PAD switch
The PAD setting provides a -10 or -20 dB reduction in
sensitivity and is commonly referred to as attenuation.
To access the PAD switch unscrew the lower section of
the body to reveal the switch (fi gure 6)
Figure 6 - PAD switch
A small screwdriver or pen can be used to alter the
switch positions as required.
A choice between 0dB, -10dB and -20dB settings can
be selected (fi gure 7). We recommend you start with
