Renesas MCU Board for 4513/4514 Group MCUs M34514T-MCU - Manual (Page 17)

( 17 / 42 )
Table 4.3 Functions of switches (2/2)
Does not connect the pullup resistor 68
k
Ω to the ports P0
0
and P0
1
.
Connects the pullup resistor 68 k Ω to
the ports P0
0
and P0
1
.
Does not connect the pullup resistor 68
k
Ω to the ports P0
2
and P0
3
.
Connects the pullup resistor 68 k Ω to
the ports P0
2
and P0
3
.
Does not connect the pullup resistor 68
k
Ω to the ports P1
0
and P1
1
.
Connects the pullup resistor 68 k Ω to
the ports P1
0
and P1
1
.
Does not connect the pullup resistor 68
k
Ω to the ports P1
2
and P1
3
.
Connects the pullup resistor 68 k Ω to
the ports P1
2
and P1
3
.
Operates for 4514 Group.
Operates for 4513 Group.
Label Switch position Description Factory-setting
SW4
SW5
SW6
SW7
SW8
OFF
ON
OFF
ON
OFF
ON
OFF
ON
514
OFF
OFF
OFF
OFF
514
513
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
514
514
513
513
