Raymarine A65 User Manual
Page 71
Chapter 4: Using the Chartplotter
71
5. When you arrive at the target waypoint an alarm sounds and a warning mes-
sage is displayed. To de-activate this alarm, press any key.
6. To set the cross track error (XTE) to zero and move the origin to the actual ves-
sel position press RESTART XTE.The The BOD and BVD lines are now aligned.
7. To stop navigating to the waypoint, press STOP GOTO. The BOD and BVD lines
are removed.
Note:
For more information on navigating with Waypoints, please refer Chapter 3: Work-
1.0nm
North-Up
Relative Motion
Position
N 25°18.160 W 080°19.397 -.-°T 0.0nm
D8636-2
WPT 0005
STOP GOTO
STOP GOTO
RESTART
TE
RESTART
TE
Bearing from Origin to Destination:
dashed line marking original
course of GOTO (unchanged)
Bearing from Vessel to Destination:
dashed (blue) line marking actual
current course of GOTO (updated)
Target Waypoint
