GROUP INDEX
Group Name Page
CRANKCASE GROUP ............................................................................... 6
CRANKSHAFT GROUP ............................................................................ 12
INTAKE and EXHAUST GROUP ............................................................... 16
GOVERNOR GROUP ............................................................................... 22
COOLING and STARTING GROUP ......................................................... 24
FUEL, LUBRICANT GROUP ..................................................................... 26
ELECTRIC DEVICE GROUP .................................................................... 34
- 5 - '00-07
SYMBOL DESCRIPTION
AY .......................... ASSEMBLY
CP .......................... COMPLETE
EX .......................... EXPORT (from Japan)
FIG. ........................ FIGURE
FR. ......................... FRONT
" .............................. INCH
INCL. ...................... INCLUDE
~L ........................... LITER
L= ........................... LENGTH (in. mm)
L.H. (LH) ................ LEFT-HAND SIDE
MECH .................... MECHANICAL
NO (NON) .............. NONE
OPT. ....................... OPTIONAL
O.S. ........................ OVER SIZE
SYMBOL DESCRIPTION
P= .......................... PITCH (in mm)
P.T.O. (PTO) .......... POWER TAKE OFF
REF. ....................... REFERENCE
R.H. (RH) ............... RIGHT HAND SIDE
RR. ......................... REAR
STD. ....................... STANDARD
SW ......................... SWITCH
T= ........................... THICKNESS (in mm)
UN .......................... UNIT
U.S. ........................ UNDER SIZE
~V .......................... VOLTAGE
~W ......................... WATT
W/ .......................... WITH
W/O ........................ WITHOUT
INDEX OF DESCRIPTION SYMBOLS
