SECTION 2 CRANKSHAFT GROUP
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
395 228-22801-13 LARGE END BEARING 2 STD. 200
228-22802-13 LARGE END BEARING 2 0.25mm undersize 200
228-22803-13 LARGE END BEARING 2 0.50mm undersize 200
500 228-22421-21 FLYWHEEL CP 1 DY30 / DY35 200
262-22401-01 FLYWHEEL CP 1 DY41 / DY42 200
510 228-22420-23 FLYWHEEL 1 DY30 / DY35 200
262-22401-03 FLYWHEEL 1 DY41 / DY42 200
520 228-71001-03 RING GEAR 1 Electric Start 200
530 243-15011-03 PIPE KNOCK 2 Electric Start 200
540 004-11082-50 SCREW 4 Electric Start 200
640 228-24406-03 DRIVING SHAFT 1 STD. 1" key, 3/8"-24UNF 200
228-24407-03 DRIVING SHAFT 1 Generator, SAE Taper 200
228-24408-03 DRIVING SHAFT 1 Pump, 1" threaded 200
228-24401-03 DRIVING SHAFT 1 Metric 25mm key, M10 X 1.5 200
228-24402-13 DRIVING SHAFT 1 Generator, Metric Taper 200
228-24403-03 DRIVING SHAFT 1 Metric Pump, 25mm threaded 200
670 001-67103-00 BOLT 4 200
730 003-20100-00 SPRING WASHER 4 200
870 228-17911-23 ADAPTER 3 1 STD. 200
228-17821-03 ADAPTER 1 Generator 200
228-17920-13 ADAPTER 4 1 Pump 200
880 001-13086-00 BOLT and WASHER AY 4 200
DY30/DY35 & DY41/DY42 - 15 - '00-07
