SECTION 4 GOVERNOR GROUP
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
10 228-42302-03 GOVERNOR LEVER 1 1 400
20 228-42201-03 GOVERNOR SHAFT 1 400
25 003-10100-00 WASHER 1 400
50 003-13080-00 CLIP 1 400
55 045-00600-10 STEEL BALL 1 400
80 228-42501-23 GOVERNOR SPRING 1 400
90 228-42101-23 GOVERNOR YOKE 1 400
100 004-35051-20 SCREW and WASHER AY 2 400
105 228-45001-33 START SPRING 1 400
110 228-42310-02 GOVERNOR LEVER 2 1 400
115 002-18060-00 NUT 2 400
150 228-41701-30 GOVERNOR PLATE AY 1 400
155 228-63902-03 OIL PUMP, outer 1 400
160 001-13062-00 BOLT and WASHER AY 2 400
170 228-41910-01 GOVERNOR SLEEVE CP 1 400
180 228-42904-02 CONTROL LINK 1 400
185 023-00800-10 SPACER 1 400
186 006-26100-50 O RING 1 400
320 231-43311-01 SPEED CONTROL 1 CP 1 400
330 228-45003-03 KNOB 1 400
340 020-00800-50 WASHER 1 400
350 020-00800-10 WASHER 1 400
355 021-70800-10 FRICTION WASHER 1 400
360 004-31063-50 SCREW 1 400
365 014-90600-70 ADJUSTING SCREW 1 400
367 041-12200-10 BLIND PLUG 1 400
370 002-18060-00 NUT 1 400
380 017-90800-12 WING NUT 1 400
390 228-44201-01 WIRE BRACKET 1 CP 1 400
391 001-65061-60 BOLT 1 400
392 002-18060-00 NUT 1 400
393 003-20600-00 SPRING WASHER 1 400
395 014-90600-40 ADJUSTING SCREW 1 400
460 040-11200-30 PLUG 1 400
465 003-70120-00 GASKET, aluminum 1 400
900 228-45004-03 LOCK PLATE 1 400
910 033-00500-10 RIVET 1 400
DY30/DY35 & DY41/DY42 - 23 - '00-07
