SECTION 7 ELECTRIC DEVICE GROUP
REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.
10 228-70401-01 GENERATOR CP 1 STD. 30 watt 700
228-70402-01 GENERATOR CP 1 45 watt 700
228-70412-01 GENERATOR CP 1 65 watt 700
228-70410-01 GENERATOR CP 1 180 watt 700
-1 228-70401-08 FLYWHEEL 1 STD. 30 watt 700
228-70404-08 FLYWHEEL 1 45 watt 700
228-70415-08 FLYWHEEL 1 65 watt 700
228-70410-08 FLYWHEEL 1 180 watt 700
-5 228-70402-08 STATOR CP 1 STD. 30 watt 700
228-70403-08 STATOR CP 1 45 watt 700
228-70414-08 STATOR CP 1 65 watt 700
228-70411-08 STATOR CP 1 180 watt 700
35 004-35041-20 SCREW and WASHER AY 4 700
46 004-11061-00 SCREW 3 700
90 228-75002-01 CLAMP CP 1 700
140 002-18080-00 NUT 2 700
160 003-20080-00 SPRING WASHER 2 700
200 228-40630-01 CONTROL BOX 1 700
201 001-13082-00 BOLT and WASHER AY 1 700
202 001-13061-20 BOLT and WASHER AY 1 700
203 001-13062-00 BOLT and WASHER AY 1 700
210 073-20010-90 LABEL, starter switch 1 700
220 066-00003-30 SWITCH 1 700
-1 066-00099-80 KEY 2 700
291 228-71901-01 REGULATOR CP 1 30 & 45 & 65 watt 700
228-71910-01 REGULATOR CP 1 180 watt 700
301 001-65062-50 BOLT 1 700
305 056-61000-21 CLAMP 1 700
311 001-65061-00 BOLT 1 700
312 003-2060-00 SPRING WASHER 2 700
313 003-10060-00 WASHER 2 700
314 002-17060-00 NUT 2 700
340 228-73101-01 WIRE 1 CP 1 700
345 228-73108-01 WIRE 2 CP 1 700
346 056-30000-20 WIRE BAND 1 700
* 228-73122-01 WIRE 5 CP 1 180 watt only, Not Shown
DY30/DY35 & DY41/DY42 - 35 - '00-07
