SECTION 7
ELECTRIC DEVICE GROUP - STARTER MOTOR
REF.
PART NO.
DESCRIPTION
QTY.
REMARKS
FROM-TOFIG.210
120
210-70502-10
STARTING MOTOR AY
1
710
-2
210-70539-08
BRUSH (+)
2
710
-3
210-70541-08
BRUSH SPRING
4
710
-4
210-70538-08
BRUSH HOLDER
1
710
-6
210-70532-08
ARMATURE
1
710
-7
210-70544-08
PINION AY
1
710
-8
210-70534-08
PINION STOPPER SET
1
710
-9
210-70545-08
GEAR CASE AY
1
710
-10
210-70540-08
BRUSH (-)
2
710
-11
210-70537-18
REAR COVER AY
1
710
-12
210-70542-08
REAR COVER METAL
1
710
-13
210-70551-08
BLIND COVER
1
710
-14
210-70546-08
SHIFT LEVER KIT
1
710
-15
210-70548-08
MAGNETIC SWITCH AY
1
710
-17
210-70549-08
BOLT
2
710
-25
210-70533-08
THRUST WASHER KIT
1
710
-26
210-70535-08
FIELD COIL
1
710
-27
210-70508-08
SCREW
4
710
-28
210-70543-08
CENTER PLATE
1
710
-29
210-70547-08
GEAR CASE METAL
1
710
-30
210-70550-18
DUST COVER KIT
1
710
DY30/DY35 & DY41/DY42
- 37 -
'00-07
