Renesas H8SX/1651 User Manual
Page 30
Section 4 Verifying Operation
Rev. 2.00 Sep. 08, 2008 Page 16 of 20
REJ10J1394-0200
⎯ To use the crystal oscillator mounted on the evaluation chip board
Install the crystal oscillator into the crystal oscillator terminals on the evaluation chip
board.
Evaluation chip
board
Crystal oscillator terminals
Crystal
oscillator
Enlarged
view
X1 X2
Figure 11 Installing the Clock Oscillator
